1. 在qml显示html并通讯
main.qml
import QtQuick 2.12
import QtQuick.Window 2.12
import QtWebEngine 1.2
import QtQuick.Controls
Window {id:mainWindowwidth: 640height: 480visible: truetitle: qsTr("WebEngine + ECharts (By: GongJianBo1992)")Column {anchors.fill: parentspacing: 10Rectangle {height: mainWindow.height * 0.8 // 占 80% 高度width: mainWindow.widthWebEngineView{id: webViewanchors.fill: parent//@disable-check M7url:"file:///./test.html"}}Button {text: "随机更新销量数据"width: 200height: 40anchors.horizontalCenter: parent.horizontalCenteronClicked: {// 生成随机数据（5个10-100的整数）let newData = [];for (let i = 0; i < 5; i++) {newData.push(Math.floor(Math.random() * 90 + 10));}webView.runJavaScript("updateData(" + JSON.stringify(newData) + ")");}}}
}
html
<!DOCTYPE html>
<html>
<head><meta charset="UTF-8"><title>ECharts in QML</title><!-- 引入 ECharts --><script src="echarts.min.js"></script><style>body { margin: 0; overflow: hidden; } /* 去除边距和滚动条 */#chartContainer { width: 100vw; height: 100vh; } /* 占满整个视图 */</style>
</head>
<body><div id="chartContainer"></div><script>// 初始化图表const chartDom = document.getElementById('chartContainer');const myChart = echarts.init(chartDom);let option = {xAxis: {type: 'category',data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']},yAxis: {type: 'value'},dataZoom: {type: 'inside', //放大缩小x轴数值},tooltip: {trigger: 'axis',axisPointer: {type: 'cross',label: {backgroundColor: '#6a7985'}}},series: [{data: [820, 932, 901, 934, 1290, 1330, 1320],type: 'line',smooth: true}]};myChart.setOption(option);// 供 QML 调用的更新函数function updateData(newData) {option.series[0].data = newData;myChart.setOption(option);}// 窗口大小变化时自适应window.onresize = () => myChart.resize();</script>
</body>
</html>
python
import sys
from PySide6 import QtWidgets, QtQml
from PySide6.QtGui import QGuiApplication
import PySide6.QtWebEngineCoreif __name__ == "__main__":# app = QGuiApplication().instance()app = QtWidgets.QApplication(sys.argv)engine = QtQml.QQmlApplicationEngine()engine.load("main.qml")if not engine.rootObjects():sys.exit(-1)sys.exit(app.exec())
案例地址 ：https://gitee.com/lj-fang/qml-html
